Julabo

Heating circulator MAGIO MS/MX

For precise temperature control of internal and external applications.

  • Simple control of complex applications
  • Infinitely adjustable, extremely powerful pressure and suction pump
  • Large, high-resolution TFT touch display with multilingual user interface
  • Medium-contacting parts made of stainless steel
  • Integrated programmer
  • External Pt100 connection
  • USB interface
  • RS232 interface
  • Ethernet interface
  • High quality thermal insulation of the bath tanks
  • Integrated drain cock for easy and safe emptying
  • Classification III according to DIN 12876-1
Material bath:Stainless steel
Temperature:20 ... 300 °C
Temperature stability:±0,01 °C
Max. flow rate:31 l/min
Max. delivery pressure:0.92 bar
Max. suction pressure:0.4 bar
Type of display:TFT
Programmable:Yes
With lid:Yes
Power supply:200 ... 230 V, 50/60 Hz
IP code:IP 20
Heating circulator MAGIO MS/MX


Heating circulator MAGIO MS/MX
X

Item added to basket.

Heating circulator MAGIO MS/MX

continue shoppinggo to basket

Customers also bought:

TypeVolume bathHeating capacity
kW		Opening (WxD)Bath depth
mm		Ext. dim.
(WxDxH)		Weight
kg		PKCat. No.in StockManuf. Prod. No.
MS-BC43 ... 4.5 l2130 x 150 mm150230 x 410 x 420 mm11.1146783039032504
MX-BC64.5 ... 6 l3130 x 150 mm200240 x 440 x 470 mm12.8146783109033506
MX-BC128.5 ... 12 l3220 x 150 mm200330 x 490 x 470 mm14.6146783119033512
MX-BC2619 ... 26 l3260 x 350 mm200390 x 620 x 480 mm21.4146783129033526
