OPTIMA^® 5 capillary columns for GC

5% phenyl - 95% dimethylpolysiloxane

USP G27, G36 nonpaolar standard phase with large range of application similar phases: Permabond^® SE-52 , SE-54, SE-52, DB-5, HP-5, SPB-5, CP-Sil 8, Rtx-5, 007-5, BP5, MDN-5, AT-5, ZB-5 for columns with 0.1 to 0.32mm ID and films <3µm the max. temperature for isothermal operation is 340°C, the max. temperature for short isotherms in a temperature programme is 360°C for 0.53mm ID columns with films < 3µm the max. temperatures are 320 and 340°C, resp. for thick film columns with films ≥ 3µm the max. temperatures are 300 and 320°C, resp.

Further lengths available on request.

Polarity:

Nonpolar


OPTIMA® 5 capillary columns for GC

Item added to basket.

OPTIMA^® 5 capillary columns for GC

continue shopping go to basket

Customers also bought:

Material column	USP listing	Film thickness µm	Int. Ø mm	Length m	Temperature max isotherm °C	Max. temperature programme °C	PK	Cat. No.	Manuf. Prod. No.
Quartz glass	G27, G36	0.1	0.1	10	340	360	1	4003235	726846.10
Quartz glass	G27, G36	0.1	0.25	25	340	360	1	9003709	726911.25
Quartz glass	G27, G36	0.25	0.25	25	340	360	1	9003715	726056.25
Quartz glass	G27, G36	0.35	0.25	25	340	360	1	9003719	726623.25
Quartz glass	G27, G36	0.5	0.25	25	340	360	1	9003723	726099.25
Quartz glass	G27, G36	1	0.25	25	340	360	1	9003727	726807.25
Quartz glass	G27, G36	0.1	0.25	30	340	360	1	9003710	726911.30
Quartz glass	G27, G36	0.25	0.25	30	340	360	1	9003716	726056.30
Quartz glass	G27, G36	0.35	0.25	30	340	360	1	9003720	726623.30
Quartz glass	G27, G36	0.5	0.25	30	340	360	1	9003724	726099.30
Quartz glass	G27, G36	1	0.25	30	340	360	1	9003728	726807.30
Quartz glass	G27, G36	0.1	0.25	50	340	360	1	9003711	726911.50
Quartz glass	G27, G36	0.25	0.25	50	340	360	1	9003717	726056.50
Quartz glass	G27, G36	0.35	0.25	50	340	360	1	9003721	726623.50
Quartz glass	G27, G36	0.5	0.25	50	340	360	1	9003725	726099.50
Quartz glass	G27, G36	1	0.25	50	340	360	1	9003729	726807.50
Quartz glass	G27, G36	0.1	0.25	60	340	360	1	9003712	726911.60
Quartz glass	G27, G36	0.25	0.25	60	340	360	1	9003718	726056.60
Quartz glass	G27, G36	0.35	0.25	60	340	360	1	9003722	726623.60
Quartz glass	G27, G36	0.5	0.25	60	340	360	1	9003726	726099.60
Quartz glass	G27, G36	1	0.25	60	340	360	1	9003730	726807.60
Quartz glass	G27, G36	0.1	0.32	25	340	360	1	9003733	726313.25
Quartz glass	G27, G36	0.25	0.32	25	340	360	1	9003738	726314.25
Quartz glass	G27, G36	0.35	0.32	25	340	360	1	9003742	726628.25
Quartz glass	G27, G36	0.5	0.32	25	340	360	1	9003746	726316.25
Quartz glass	G27, G36	1	0.32	25	340	360	1	9003751	726325.25
Quartz glass	G27, G36	3	0.32	25	300	320	1	9003755	726809.25
Quartz glass	G27, G36	5	0.32	25	300	320	1	9003760	726934.25
Quartz glass	G27, G36	0.1	0.32	30	340	360	1	9003734	726313.30
Quartz glass	G27, G36	0.25	0.32	30	340	360	1	9003739	726314.30
Quartz glass	G27, G36	0.35	0.32	30	340	360	1	9003743	726628.30
Quartz glass	G27, G36	0.5	0.32	30	340	360	1	9003747	726316.30
Quartz glass	G27, G36	1	0.32	30	340	360	1	9003752	726325.30
Quartz glass	G27, G36	3	0.32	30	300	320	1	9003756	726809.30
Quartz glass	G27, G36	5	0.32	30	300	320	1	9003761	726934.30
Quartz glass	G27, G36	0.1	0.32	50	340	360	1	9003735	726313.50
Quartz glass	G27, G36	0.25	0.32	50	340	360	1	9003740	726314.50
Quartz glass	G27, G36	0.35	0.32	50	340	360	1	9003744	726628.50
Quartz glass	G27, G36	0.5	0.32	50	340	360	1	9003748	726316.50
Quartz glass	G27, G36	1	0.32	50	340	360	1	9003753	726325.50
Quartz glass	G27, G36	3	0.32	50	300	320	1	9003757	726809.50
Quartz glass	G27, G36	0.1	0.32	60	340	360	1	9003736	726313.60
Quartz glass	G27, G36	0.25	0.32	60	340	360	1	9003741	726314.60
Quartz glass	G27, G36	0.35	0.32	60	340	360	1	9003745	726628.60
Quartz glass	G27, G36	0.5	0.32	60	340	360	1	9003749	726316.60
Quartz glass	G27, G36	1	0.32	60	340	360	1	9003754	726325.60
Quartz glass	G27, G36	3	0.32	60	300	320	1	9003758	726809.60
Quartz glass	G27, G36	0.5	0.53	25	320	340	1	4003155	726523.25
Quartz glass	G27, G36	1	0.53	25	320	340	1	4003168	726541.25
Quartz glass	G27, G36	2	0.53	25	320	340	1	4003158	726525.25
Quartz glass	G27, G36	5	0.53	25	300	320	1	4003261	726916.25
Quartz glass	G27, G36	0.5	0.53	30	320	340	1	4003156	726523.30
Quartz glass	G27, G36	1	0.53	30	320	340	1	4003169	726541.30
Quartz glass	G27, G36	2	0.53	30	320	340	1	4003159	726525.30
Quartz glass	G27, G36	5	0.53	30	300	320	1	4003262	726916.30
Quartz glass	G27, G36	2	0.53	50	320	340	1	4003160	726525.50
Quartz glass	G27, G36	5	0.53	50	300	320	1	4003263	726916.50
Quartz glass	G27, G36	2	0.53	60	320	340	1	4003161	726525.60

Material column Quartz glass

USP listing G27, G36

Film thickness 0.1µm

Int. Ø 0.1mm

Length 10m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 4.003 235

Material column Quartz glass

USP listing G27, G36

Film thickness 0.1µm

Int. Ø 0.25mm

Length 25m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 709

Material column Quartz glass

USP listing G27, G36

Film thickness 0.25µm

Int. Ø 0.25mm

Length 25m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 715

Material column Quartz glass

USP listing G27, G36

Film thickness 0.35µm

Int. Ø 0.25mm

Length 25m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 719

Material column Quartz glass

USP listing G27, G36

Film thickness 0.5µm

Int. Ø 0.25mm

Length 25m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 723

Material column Quartz glass

USP listing G27, G36

Film thickness 1µm

Int. Ø 0.25mm

Length 25m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 727

Material column Quartz glass

USP listing G27, G36

Film thickness 0.1µm

Int. Ø 0.25mm

Length 30m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 710

Material column Quartz glass

USP listing G27, G36

Film thickness 0.25µm

Int. Ø 0.25mm

Length 30m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 716

Material column Quartz glass

USP listing G27, G36

Film thickness 0.35µm

Int. Ø 0.25mm

Length 30m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 720

Material column Quartz glass

USP listing G27, G36

Film thickness 0.5µm

Int. Ø 0.25mm

Length 30m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 724

Material column Quartz glass

USP listing G27, G36

Film thickness 1µm

Int. Ø 0.25mm

Length 30m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 728

Material column Quartz glass

USP listing G27, G36

Film thickness 0.1µm

Int. Ø 0.25mm

Length 50m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 711

Material column Quartz glass

USP listing G27, G36

Film thickness 0.25µm

Int. Ø 0.25mm

Length 50m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 717

Material column Quartz glass

USP listing G27, G36

Film thickness 0.35µm

Int. Ø 0.25mm

Length 50m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 721

Material column Quartz glass

USP listing G27, G36

Film thickness 0.5µm

Int. Ø 0.25mm

Length 50m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 725

Material column Quartz glass

USP listing G27, G36

Film thickness 1µm

Int. Ø 0.25mm

Length 50m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 729

Material column Quartz glass

USP listing G27, G36

Film thickness 0.1µm

Int. Ø 0.25mm

Length 60m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 712

Material column Quartz glass

USP listing G27, G36

Film thickness 0.25µm

Int. Ø 0.25mm

Length 60m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 718

Material column Quartz glass

USP listing G27, G36

Film thickness 0.35µm

Int. Ø 0.25mm

Length 60m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 722

Material column Quartz glass

USP listing G27, G36

Film thickness 0.5µm

Int. Ø 0.25mm

Length 60m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 726

Material column Quartz glass

USP listing G27, G36

Film thickness 1µm

Int. Ø 0.25mm

Length 60m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 730

Material column Quartz glass

USP listing G27, G36

Film thickness 0.1µm

Int. Ø 0.32mm

Length 25m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 733

Material column Quartz glass

USP listing G27, G36

Film thickness 0.25µm

Int. Ø 0.32mm

Length 25m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 738

Material column Quartz glass

USP listing G27, G36

Film thickness 0.35µm

Int. Ø 0.32mm

Length 25m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 742

Material column Quartz glass

USP listing G27, G36

Film thickness 0.5µm

Int. Ø 0.32mm

Length 25m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 746

Material column Quartz glass

USP listing G27, G36

Film thickness 1µm

Int. Ø 0.32mm

Length 25m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 751

Material column Quartz glass

USP listing G27, G36

Film thickness 3µm

Int. Ø 0.32mm

Length 25m

Temperature max isotherm 300°C

Max. temperature programme 320°C

Cat. No. 9.003 755

Material column Quartz glass

USP listing G27, G36

Film thickness 5µm

Int. Ø 0.32mm

Length 25m

Temperature max isotherm 300°C

Max. temperature programme 320°C

Cat. No. 9.003 760

Material column Quartz glass

USP listing G27, G36

Film thickness 0.1µm

Int. Ø 0.32mm

Length 30m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 734

Material column Quartz glass

USP listing G27, G36

Film thickness 0.25µm

Int. Ø 0.32mm

Length 30m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 739

Material column Quartz glass

USP listing G27, G36

Film thickness 0.35µm

Int. Ø 0.32mm

Length 30m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 743

Material column Quartz glass

USP listing G27, G36

Film thickness 0.5µm

Int. Ø 0.32mm

Length 30m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 747

Material column Quartz glass

USP listing G27, G36

Film thickness 1µm

Int. Ø 0.32mm

Length 30m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 752

Material column Quartz glass

USP listing G27, G36

Film thickness 3µm

Int. Ø 0.32mm

Length 30m

Temperature max isotherm 300°C

Max. temperature programme 320°C

Cat. No. 9.003 756

Material column Quartz glass

USP listing G27, G36

Film thickness 5µm

Int. Ø 0.32mm

Length 30m

Temperature max isotherm 300°C

Max. temperature programme 320°C

Cat. No. 9.003 761

Material column Quartz glass

USP listing G27, G36

Film thickness 0.1µm

Int. Ø 0.32mm

Length 50m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 735

Material column Quartz glass

USP listing G27, G36

Film thickness 0.25µm

Int. Ø 0.32mm

Length 50m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 740

Material column Quartz glass

USP listing G27, G36

Film thickness 0.35µm

Int. Ø 0.32mm

Length 50m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 744

Material column Quartz glass

USP listing G27, G36

Film thickness 0.5µm

Int. Ø 0.32mm

Length 50m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 748

Material column Quartz glass

USP listing G27, G36

Film thickness 1µm

Int. Ø 0.32mm

Length 50m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 753

Material column Quartz glass

USP listing G27, G36

Film thickness 3µm

Int. Ø 0.32mm

Length 50m

Temperature max isotherm 300°C

Max. temperature programme 320°C

Cat. No. 9.003 757

Material column Quartz glass

USP listing G27, G36

Film thickness 0.1µm

Int. Ø 0.32mm

Length 60m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 736

Material column Quartz glass

USP listing G27, G36

Film thickness 0.25µm

Int. Ø 0.32mm

Length 60m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 741

Material column Quartz glass

USP listing G27, G36

Film thickness 0.35µm

Int. Ø 0.32mm

Length 60m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 745

Material column Quartz glass

USP listing G27, G36

Film thickness 0.5µm

Int. Ø 0.32mm

Length 60m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 749

Material column Quartz glass

USP listing G27, G36

Film thickness 1µm

Int. Ø 0.32mm

Length 60m

Temperature max isotherm 340°C

Max. temperature programme 360°C

Cat. No. 9.003 754

Material column Quartz glass

USP listing G27, G36

Film thickness 3µm

Int. Ø 0.32mm

Length 60m

Temperature max isotherm 300°C

Max. temperature programme 320°C

Cat. No. 9.003 758

Material column Quartz glass

USP listing G27, G36

Film thickness 0.5µm

Int. Ø 0.53mm

Length 25m

Temperature max isotherm 320°C

Max. temperature programme 340°C

Cat. No. 4.003 155

Material column Quartz glass

USP listing G27, G36

Film thickness 1µm

Int. Ø 0.53mm

Length 25m

Temperature max isotherm 320°C

Max. temperature programme 340°C

Cat. No. 4.003 168

Material column Quartz glass

USP listing G27, G36

Film thickness 2µm

Int. Ø 0.53mm

Length 25m

Temperature max isotherm 320°C

Max. temperature programme 340°C

Cat. No. 4.003 158

Material column Quartz glass

USP listing G27, G36

Film thickness 5µm

Int. Ø 0.53mm

Length 25m

Temperature max isotherm 300°C

Max. temperature programme 320°C

Cat. No. 4.003 261

Material column Quartz glass

USP listing G27, G36

Film thickness 0.5µm

Int. Ø 0.53mm

Length 30m

Temperature max isotherm 320°C

Max. temperature programme 340°C

Cat. No. 4.003 156

Material column Quartz glass

USP listing G27, G36

Film thickness 1µm

Int. Ø 0.53mm

Length 30m

Temperature max isotherm 320°C

Max. temperature programme 340°C

Cat. No. 4.003 169

Material column Quartz glass

USP listing G27, G36

Film thickness 2µm

Int. Ø 0.53mm

Length 30m

Temperature max isotherm 320°C

Max. temperature programme 340°C

Cat. No. 4.003 159

Material column Quartz glass

USP listing G27, G36

Film thickness 5µm

Int. Ø 0.53mm

Length 30m

Temperature max isotherm 300°C

Max. temperature programme 320°C

Cat. No. 4.003 262

Material column Quartz glass

USP listing G27, G36

Film thickness 2µm

Int. Ø 0.53mm

Length 50m

Temperature max isotherm 320°C

Max. temperature programme 340°C

Cat. No. 4.003 160

Material column Quartz glass

USP listing G27, G36

Film thickness 5µm

Int. Ø 0.53mm

Length 50m

Temperature max isotherm 300°C

Max. temperature programme 320°C

Cat. No. 4.003 263

Material column Quartz glass

USP listing G27, G36

Film thickness 2µm

Int. Ø 0.53mm

Length 60m

Temperature max isotherm 320°C

Max. temperature programme 340°C

Cat. No. 4.003 161

Custom-made columns to your specifications available on request.

Each column is individually tested and supplied with test certificate and test chromatogram, but without fittings or ferrules. Column ends are melted or closed with septa, and thus protected from atmospheric oxygen.

Additionally, we supply the corresponding test mixture with each column.

OPTIMA^® 5 capillary columns for GCManufacturers:Macherey-Nagel GmbH & Co. KGE-Classes:Alternate products:

OPTIMA® 5 capillary columns for GC

OPTIMA^® 5 capillary columns for GC
