Highly dynamic temperature control systems PRESTO™, air-cooled Highly dynamic temperature control systems suitable for high-precision, external temperature control tasks, such as reactor temperature control, material tests, or temperature simulation.
Space-optimised, compact design Short heating and cooling times Large working temperature ranges without changing heat transfer media Minimized floor space due to side panels without ventilation slits 5.7" TFT touch screen SD card slot Interfaces for USB, Ethernet, RS232, Modbus Connections for alarm output, Pt100 external sensor, and standby-input ICC cascade temperature control Electronic level indicator Integrated programmer for 8 x 60 steps Class III (FL) acc. to DIN 12876-1
With air-cooled refrigerating machine A 38, A 41, and A 70 with natural refrigerants Power supply: 230 V, 50 Hz
X Item added to basket.
Highly dynamic temperature control systems PRESTO™, air-cooled
Type Temperature Temperature stability Max. flow rate Max. delivery Refrigerant Cooling Heating capacity Ext. dim. Weight IP code PK Cat. No. in Stock Manuf. Prod. No. A 30 -30 ... 250 °C ±0,01 ... ±0,05 25 0.5 R452A 0,5 2.7 250 x 590 x 620 mm 62 IP 21 1 9857915 9420300 A 38 -45 ... 250 °C ±0,01 ... ±0,05 50 1.6 R1270 0,91 2.7 330 x 750 x 670 mm 80 IP 20 1 4686941 9420381.N1 A 40 -40 ... 250 °C ±0,01 ... ±0,05 40 1.7 1,2 2.7 330 x 590 x 670 mm 79 IP 21 1 9857916 9420401 A 41 -45 ... 250 °C ±0,01 ... ±0,05 50 1.6 R1270 1,47 2.7 330 x 750 x 670 mm 80 IP 20 1 4686942 9420411.N1 A 45 -45 ... 250 °C ±0,05 ... ±0,1 80 3 R452A 3,5 6 530 x 665 x 1,260 mm 210 IP 20 1 4672122 9420452 A 45t -45 ... 250 °C ±0,05 ... ±0,1 80 3 R452A 3,5 12 530 x 665 x 1,260 mm 210 IP 20 1 4672123 9420452.T A 70 -75 ... 250 °C ±0,01 ... ±0,05 40 1.7 R449A 1,12 1.8 570 x 640 x 880 mm 140 IP 20 1 4686943 9420701.N1 A 80 -80 ... 250 °C ±0,01 ... ±0,05 40 1.7 1,2 1.8 430 x 650 x 1,260 mm 164 IP 20 1 9857918 9420801 A 80t -80 ... 250 °C ±0,01 ... ±0,05 40 1.7 1,2 3.4 430 x 650 x 1,260 mm 167 IP 20 1 9857920 9420801.T A 85 -85 ... 250 °C ±0,05 ... ±0,1 80 3 2,5 6 610 x 1,080 x 1,250 mm 365 IP 20 1 4658068 9420852
Type A 30 Temperature -30 ... 250 °C Temperature stability ±0,01 ... ±0,05°C Max. flow rate 25l/min Max. delivery
pressure 0.5bar Refrigerant R452A Cooling
capacity at 20 °C 0,5kW Heating capacity 2.7kW Ext. dim. 250 x 590 x 620 mm(WxDxH) Weight 62kg IP code IP 21 Cat. No. 9.857 915 Type A 38 Temperature -45 ... 250 °C Temperature stability ±0,01 ... ±0,05°C Max. flow rate 50l/min Max. delivery
pressure 1.6bar Refrigerant R1270 Cooling
capacity at 20 °C 0,91kW Heating capacity 2.7kW Ext. dim. 330 x 750 x 670 mm(WxDxH) Weight 80kg IP code IP 20 Cat. No. 4.686 941 Type A 40 Temperature -40 ... 250 °C Temperature stability ±0,01 ... ±0,05°C Max. flow rate 40l/min Max. delivery
pressure 1.7bar Refrigerant Cooling
capacity at 20 °C 1,2kW Heating capacity 2.7kW Ext. dim. 330 x 590 x 670 mm(WxDxH) Weight 79kg IP code IP 21 Cat. No. 9.857 916 Type A 41 Temperature -45 ... 250 °C Temperature stability ±0,01 ... ±0,05°C Max. flow rate 50l/min Max. delivery
pressure 1.6bar Refrigerant R1270 Cooling
capacity at 20 °C 1,47kW Heating capacity 2.7kW Ext. dim. 330 x 750 x 670 mm(WxDxH) Weight 80kg IP code IP 20 Cat. No. 4.686 942 Type A 45 Temperature -45 ... 250 °C Temperature stability ±0,05 ... ±0,1°C Max. flow rate 80l/min Max. delivery
pressure 3bar Refrigerant R452A Cooling
capacity at 20 °C 3,5kW Heating capacity 6kW Ext. dim. 530 x 665 x 1,260 mm(WxDxH) Weight 210kg IP code IP 20 Cat. No. 4.672 122 Type A 45t Temperature -45 ... 250 °C Temperature stability ±0,05 ... ±0,1°C Max. flow rate 80l/min Max. delivery
pressure 3bar Refrigerant R452A Cooling
capacity at 20 °C 3,5kW Heating capacity 12kW Ext. dim. 530 x 665 x 1,260 mm(WxDxH) Weight 210kg IP code IP 20 Cat. No. 4.672 123 Type A 70 Temperature -75 ... 250 °C Temperature stability ±0,01 ... ±0,05°C Max. flow rate 40l/min Max. delivery
pressure 1.7bar Refrigerant R449A Cooling
capacity at 20 °C 1,12kW Heating capacity 1.8kW Ext. dim. 570 x 640 x 880 mm(WxDxH) Weight 140kg IP code IP 20 Cat. No. 4.686 943 Type A 80 Temperature -80 ... 250 °C Temperature stability ±0,01 ... ±0,05°C Max. flow rate 40l/min Max. delivery
pressure 1.7bar Refrigerant Cooling
capacity at 20 °C 1,2kW Heating capacity 1.8kW Ext. dim. 430 x 650 x 1,260 mm(WxDxH) Weight 164kg IP code IP 20 Cat. No. 9.857 918 Type A 80t Temperature -80 ... 250 °C Temperature stability ±0,01 ... ±0,05°C Max. flow rate 40l/min Max. delivery
pressure 1.7bar Refrigerant Cooling
capacity at 20 °C 1,2kW Heating capacity 3.4kW Ext. dim. 430 x 650 x 1,260 mm(WxDxH) Weight 167kg IP code IP 20 Cat. No. 9.857 920 Type A 85 Temperature -85 ... 250 °C Temperature stability ±0,05 ... ±0,1°C Max. flow rate 80l/min Max. delivery
pressure 3bar Refrigerant Cooling
capacity at 20 °C 2,5kW Heating capacity 6kW Ext. dim. 610 x 1,080 x 1,250 mm(WxDxH) Weight 365kg IP code IP 20 Cat. No. 4.658 068
